PLC Allen Bradley Studio 5000 / RsLogix 5000

Advance to Programmable Logic Controllers (PLC)

In this course, you will build on what you have learned in “Introduction to Programmable Logic Controllers (PLC)” course to design and test more complex automation systems. You will learn to use Programmable Logic Controllers (PLC) to create more complex ladder diagram programs. The detailed operation of timer, counter and sequencer instructions in PLC logic will be studied.

advance plc

Course Contents:

1. Advanced Ladder Diagrams for Programmable Logic Controllers (PLC)

  • Use addressing/tags correctly in a PLC program.
  • Create I/O diagrams of a PLC program.
  • Create Ladder diagrams for a PLC program.

2. PLC Math and Comparison Instructions

  • Use Math instructions in a PLC program.
  • Apply Comparison instructions in a PLC program.
  • Apply Move instructions in a PLC program.

3. PLC Timers

  • Implement a TON timer in a PLC program.
  • Implement a TOF timer in a PLC program.
  • Use an RTO timer in a PLC program.

4. PLC Counters

  • Implement a CTU counter in a PLC program.
  • Use a CTD counter in a PLC program.

5. PLC Sequencers

  • Apply Sequencer instructions in a PLC program.
  • Use event activated SQO instructions in a PLC program.
  • Implement timer activated SQO instructions in a PLC program.

6. Structured Text PLC Programs

  • Create structured text programs.
  • Use structured text programming to control a mechatronics system.

7. Function Block PLC Programs

  • Create function block programs.
  • Use function block programming to control a mechatronics system.

8. Scaling

  • Use analog input and output devices.
  • Create loop diagrams.
  • Scale using the CPT instruction.
